Invacare TDX SP power wheelchair in motion, couple's walk on the marina

TDX SP2 comes equipped with excellent features that make it function effectively. TDX SP2 by Invacare boasts of durability and ultimate performance in a modern, contemporary style. Excellent manoeuvrability – indoors and out, with a wide choice of seating for optimum comfort and support. This makes it an exceptional chair ideal for individuals who need full functionality, but do not want to compromise on style. Sitting alongside the TDX SP2NB, it has a higher weight capacity with larger batteries and range ability.

One of the outstanding features in the Invacare TDX SP2 is its enhanced stability. The Invacare TDX SP2 offers maximum stability and safety; the stability lock function ensures all six wheels stay firmly on the ground on uneven terrain. The patented SureStep suspension technology enables a smooth ride while negotiating challenging surfaces. With a higher weight capacity and more excellent driving range, the TDX SP2 enables you to go further.

Invacare TDX SP power wheelchair
Invacare TDX SP power wheelchair
Invacare TDX SP power wheelchair electric lift
Invacare TDX SP power wheelchair electric lift
The Invacare TDX SP electric wheelchair electric lift
Invacare TDX SP2 wheelchair
Invacare TDX SP2 wheelchair
Invacare TDX SP power wheelchair
Invacare TDX SP power wheelchair
Invacare TDX SP power wheelchair electric lift
Invacare TDX SP power wheelchair electric lift
The Invacare TDX SP electric wheelchair electric lift
Invacare TDX SP2 wheelchair
Invacare TDX SP2 wheelchair
Invacare TDX SP power wheelchair
Invacare TDX SP power wheelchair
Invacare TDX SP power wheelchair electric lift
Invacare TDX SP power wheelchair electric lift
The Invacare TDX SP electric wheelchair electric lift
Invacare TDX SP2 wheelchair
Invacare TDX SP2 wheelchair

TDX SP2 also offers an intuitive driving experience. It has an incredibly tight turning radius, thanks to its Centre Wheel Drive; this outstanding wheelbase provides excellent manoeuvrability that gives an intuitive driving experience. Below are some key features of TDX SP2:

  • LiNX Smart Technology: This technology redefines mobility – it is behind the superb driving experience users’ experience.

  • Touchscreen technology: It comes with REM400 remote that has an impressive 3.5” colour touchscreen – it requires minimal force to operate.

  • Built-in Bluetooth: With the REM400, users can connect to 3 devices at the same time, and it has mouse mover technology.

  • Compact remote with LED display: This is ideal for users who have a limited range of motion and reduced strength.

  • Extremity control joystick: Ideal for chin control with the outer shell being resistant to saliva.

  • MEC joystick: This is perfect for those with muscle weakness or fine motor control.

Surestep Stability lock
Surestep Stability lock

Allows easy obstacle climbing and ensures a smooth downward transition.

Single Sided Fork
Single Sided Fork

Minimises the front width of the base with no protruding screws or fork parts providing a slimline front castor.

Centre Wheel drive
Centre Wheel drive

True centre wheel drive allows excellent manoeuvrability in narrow spaces and ensures an intuitive driving experience.

Seat rise and recline function
Seat rise and recline function

Seat lifter provides easy access to higher objects and the tilt allows relaxation and pressure re-distribution.

TDX SP2 Lighting system
TDX SP2 Lighting system

Attractive LED lighting system with energy saving LED Lights integrated into the base shroud.

Find a retailer

Find your dealer

Search for your nearest Invacare Retailer by completting the fields below.

Dealer map

Search for your nearest Invacare Retailer by completing the fields below.

Leave us a message

Please complete the details below to contact us.

Specifications & Downloads
Technical data
Technical data
Seat width

Seat width

380 - 530 mm

Seat depth

Seat depth

410 - 510 mm

Seat height

Seat height

450 / 475 mm 475 - 775 mm

Backrest height

Backrest height

480, 540, 560 mm

Armrest height

Armrest height

245 - 310 / 295 - 360 mm

Length of footrests

Length of footrests

290 - 460 mm

Seat angle

Seat angle

0 - 20° / 0 - 30°

Backrest angle

Backrest angle

90° - 120°

Total height

Total height

1010 - 1170 mm

Total length without footrests

Total length without footrests

980 mm

Driving unit width

Driving unit width

650 mm

Total length

Total length

1160 mm

Max. User weight

Max. User weight

180 kg / 160 kg

Battery capacity

Battery capacity

73.5 Ah (C20)

Turning diameter

Turning diameter

1120 mm

Max. climbable obstacle height

Max. climbable obstacle height

75 mm

Max. safe slope

Max. safe slope

9° / 16 %

Motor capacity

Motor capacity

2 x 324 W 2 x 340 W

Speed

Speed

6, 8, 10 or 12 km/h

Driving range

Driving range

up to 33 km

Total weight

Total weight

154 kg

Crash tested

Crash tested

Rim colour

Rim colour

Island Blue, Lights Out Matte - Black, RockStar Red, SpaceStation Silver,  Invacare Blue, Wet Black, Grape JellyBean

Shroud colour

Shroud colour

Island Blue, Lights Out Matte - Black, RockStar Red, SpaceStation Silver,  Invacare Blue, Wet Black, Grape JellyBean

Shroud colour

Comment

1. Seat cushion 430 mm
2. Additional 100 mm by armrest adjustment
3. Extended profile rail package for larger seat depth
4. Ground to seat plate without cushion
5. With seat lifter or powered tilt
6. With lifter
7. Measured from seat plate
8. Measured from footplate to seat plate
9. Depending on seat position
10. Width of wheelbase
11. Depending on configuration
12. Measurement with 73.5 Ah batteries according to ISO 7176-4 @ 6 km/h, driving range will vary by configuration (battery size, speed)
13. Invacare Modulite™ seat components are cross compatible across the Invacare power wheelchair range and partly with the Invacare Rea® family.
14. 12 km/h DuraWatt motors
