Invacare XLT Swing manual wheelchair

Manual wheelchair XLT Swing black frame man trying tie on
Manual wheelchair Invacare XLT Swing black frame

Invacare XLT Swing is simply the perfect wheelchair for everyday use. It is specially designed with excellent features that offer a wide range of support for improved independence and mobility. Its sturdy box frame construction is built entirely from titanium giving stability and rigidity without compromising on weight.  The XLT is ideal to help regain, retain and improve both mobility and independence.

The chair is designed to suit a variety of needs. It is measured, constructed and fitted to suit the precise requirements of each person, and combined with the wide range of options and accessories, the possibilities are endless.

XLT Swing is available with a range of swing away and removable legrests to help facilitate safe and convenient standing transfers.  The varying angles ensure all levels of leg and foot positions can be accommodated, making the XLT Swing a versatile active wheelchair.

Headrest: XLT is crash tested and offers a range of headrest options for additional support

Castors: A range of castor sizes support a wide range of seat heights and provides varying drive experiences.

Standard wheel: The Invacare XTL comes with optional Marathon Plus tyres for increased performance.

Front Castor Attachments: It is equipped with an easy to adjust front castor attachment for stability and performance.

Choice of footplates: Flip up and angle adjustable, to achieve the best possible range of foot and leg support and comfort for improved posture.

Find a retailer

Find your dealer

Search for your nearest Invacare Retailer by completting the fields below.

Dealer map

Search for your nearest Invacare Retailer by completing the fields below.

Leave us a message

Please complete the details below to contact us.

Specifications & Downloads

Technical data
Technical data
Seat width

Seat width

330 - 505 mm in increments of 15 mm

Seat depth

Seat depth

400/ 450/ 500 mm

Seat height

Seat height

390 - 520 mm

Knee-to-heel length

Knee-to-heel length

280 - 510 mm

Backrest angle

Backrest angle

+- 10°

Backrest height

Backrest height

200 - 490 mm

Front frame angle

Front frame angle

0 - 14°

Total width

Total width

SW + 200 mm

Total height

Total height

610 - 1050 mm

Max. User weight

Max. User weight

135 kg

Total weight

Total weight

11,3 kg

Transport weight

Transport weight

6 kg

Crash tested

Crash tested

Frame colour

Frame colour

Blue, Red, Black, Grey, Orange (available as special orders)

Colour (other)

Colour (other)

Black Nylon, Black Jemima
